Best seller
Request a quote
Benches & Racks
Commercial Power Rack
- Model
- DLR03
- Model
- DLR03
- Upright tube
- 75 × 75 × 3.0 mm steel
- MOQ
- 10 units
Best seller
Model
DLR30
Upright tube
75 × 75 × 3.0 mm steel
Hole spacing
50 mm standard, 25 mm Westside option
The rack and the cable station are usually bought separately and then placed on opposite sides of the room. The DLR02 combines them so that the transition between barbell and cable work costs a step rather than a walk.
Uprights are 75 × 75 × 3.0 mm with laser-cut hole spacing at 50 mm, which means standard rack attachments fit without adapters. The cable column carries a single 90 kg stack in a 1:2 ratio, mounted on the front face so it does not interfere with bar path.
Westside spacing is available on the bench press zone — a detail that matters more than most buyers expect, because it is what allows a lifter to set the J-hooks to their own arch rather than to the nearest hole.
| Model | DLR30 |
|---|---|
| Upright tube | 75 × 75 × 3.0 mm steel |
| Hole spacing | 50 mm standard, 25 mm Westside option |
| Cable stack | 90 kg, 1:2 ratio, magnetic pin |
| Bar capacity | 350 kg on the J-hooks |
| Dimensions (L × W × H) | 1,760 × 1,540 × 2,460 mm |
| Net weight | 286 kg |
| Included | J-hooks, spotter arms, band pegs, plate pins |
| Model | DLR02 |
| Application | Commercial gym, strength studio |
| Loading type | Free-weight bar plus cable stack |
| Material | Heavy-wall steel tube |
| MOQ | 5 sets |
| Lead time | 25–35 days after deposit and drawing approval |
| Warranty | 12 months on frames and components |
| Colour | Customisable — RAL or Pantone reference |
| Branding | Logo plate, decal or embroidered upholstery tag |
Specifications are current at the time of publication and may be revised without notice. Confirmed dimensions are issued on the order drawing before production. Packing volume is indicative — ask us for the container loading plan specific to your quantity mix.
- 75 × 75 × 3.0 mm uprights with 50 mm laser-cut hole spacing
- Optional Westside spacing through the bench press zone
- Front-mounted single column with 90 kg stack, 1:2 ratio
- UHMW-PE lined J-hooks and safety spotter arms included
- Band pegs and plate storage pins on the rear posts
- Numbered uprights so two lifters can reset the rack identically
This model is specified for the following environments:
Commercial fitness clubsBoutique strength studiosUniversity sports centresSports academies
Sizing the whole floor rather than one machine? Send a floor plan and we will propose a station count for your membership and traffic pattern.
Equipment is packed for sea freight as standard: frames foam-wrapped, panels edge-protected, hardware bagged and labelled per unit, then steel-banded onto pallets.
- Assembled or knocked-down packing depending on model and container utilisation
- Container loading plan issued before booking, with supervised loading photographs
- FOB, CIF, CFR, DAP and DDP terms available — tell us the port and we will quote all of them
- Wood packaging with IPPC heat treatment marks where required by destination
Commercial equipment earns its money over years, so our support is organised around keeping a floor running rather than closing a sale.
- Warranty: 12 months on frames and components. Terms are confirmed in writing on the order.
- Spare parts: cables, pulleys, bearings, pads and hardware held against every order number.
- Documentation: assembly manual, torque table and parts diagram supplied per model.
- Installation: remote support as standard; on-site supervision available for full fit-outs.
Benches & Racks
Half Rack with Integrated Cable Station
MODEL DLR02
A 75 mm upright half rack with a front-mounted dual pulley column — squat and press inside the rack, then walk one step forward for cable work without giving up floor space.
75 × 75 × 3.0 mm uprights with 50 mm laser-cut hole spacing
Optional Westside spacing through the bench press zone
Front-mounted single column with 90 kg stack, 1:2 ratio
UHMW-PE lined J-hooks and safety spotter arms included
Request a quotation
Pricing for Half Rack with Integrated Cable Station — reply within one working day.
MOQ
5 sets
Lead time
25–35 days after deposit and drawing approval
Prefer to talk?
Also consider
Machines that pair with this one
Benches & Racks
Adjustable Weight Bench
- Model
- DLB-4002
- Model
- DLB-4002
- Backrest range
- 0–85°, 8 positions
- MOQ
- 20 units
Benches & Racks
Flat Olympic Bench with Spotter Platform
- Model
- DLB-4005
- Model
- DLB-4005
- Frame tube
- 100 × 50 × 3.0 mm steel, 50 mm uprights
- MOQ
- 10 units
Benches & Racks
Adjustable Weight Multi-Function FID Bench
- Model
- DL850
- Model
- DL850
- Incline range
- 0 to 90degrees, 8 positions, plus decline
- MOQ
- 10 units
Ordering
Buying questions we answer every week
Photograph the container condition before unloading where possible, and record any shortage or damage on the delivery receipt. Send us the photographs, the packing list and the container number and we will investigate against our loading records and resolve it with you directly. Loading photographs are taken specifically so this process is quick.
Yes. Every order is filed with its component list, so a cable or pad bought two years later is the same part. Cables, pulleys, bearings and pads are standardised across a platform family, which keeps stock practical. Less common components may require a production run, and we will state the lead time honestly.
Ratings are published per model and appear in the specification table on each product page — typically 250 to 500 kg for racks and presses, and 180 kg user rating for cardio. Ratings are verified in our load testing rather than estimated. If you need a rating for a structural assessment or a tender, we will supply it in writing.
Yes. We match frame powder coat and upholstery vinyl to a RAL, Pantone or physical sample, and retain the approved coupon for repeat orders. This is common for hotel and residential projects where the gym needs to read as part of the interior rather than an addition to it.
Yes, and we would rather you specified them at the same time. Flooring, storage walls, racks, mats, kettlebell sets, medicine balls, ropes, collars and attachments all ship in the same container, matched in quantity to the machines you have ordered. Buying accessories locally afterwards usually costs more and arrives in the wrong specification.
